| Property | Unit | STC1000C5-8 | STC1000C6-8 |
| Boom Length | m | 50.5 (Main) | 60 (Main) |
| Counterweight | t | 21.5 (Standard) | 26.5/32.5 (Standard) |
| Overall Dimensions (L×W×H) | mm | 14980×3000×3940 | 14985×3000×3920 |
| Total Weight | kg | 50000 | 50000 |
| Max Rated Load Capacity | t | 100 | 100 |
| Engine Model | - | Wangzi KK09380-60 | Wangzi KK09380-60 |
| Engine Power | kW/rpm | 280/1900 | 280/1900 |
| Max Torque | N.m/rpm | 1800/1100-1450 | 1800/1100-1450 |
| Max Travel Speed | km/h | 80 | 80 |
| Min Turning Radius | m | 12 | 12 |
| Approach/Departure Angle | ° | ≥20 / ≥13 | ≥20 / ≥13 |
| Max Gradeability | % | 45 | 45 |
| Fuel Consumption | L/100km | ≤43 | ≤43 |
| Swing Radius (Rear) | m | 4.42 | 4.42 |
| Max Moment (Basic Boom) | kN.m | 3557 | 3557 |
| Max Moment (Full Boom) | kN.m | 2372 | 2293 |
| Basic Boom Length | m | 12.9 | 13 |
| Max Boom + Jib | m | 68 | 77.5 |
| Max Boom + Extension | m | 77.5 | 87 |
| Max Load (Full Boom) | t | 16.5 | 13.2 |
| Max Lifting Height | m | 51 | 60.5 |
| Max Working Radius | m | 44 | 52 |
Q: What's the lead time for orders?
A: Standard models ship in 15-30 days; customized units require 30-45 days.
Q: Do you provide after-sales service overseas?
A: Yes, we have partnered service centers in key regions.
Q: Can we customize the appearance of the crane?
A:Of course! We can customize what you want
Q: What documents do you provide for export?
A: Full export package (Commercial Invoice, Packing List, Bill of Lading, COC, etc.).
Q: How do I place an order?
A: Contact us via email/phone for a quote, then confirm with a PO.
